To facilitate ease of connection for LED strips, assemblies & modules we offer a variety of products from basic link cables, connector attach, distribution boxes and In line IDC connectors for flexible LED strips.

Types include:

  • Multi-way parallel connection distribution boxes
  • Multiway RGB and RGBW LED assembly connectors
  • Flexible Strip connectors

PSU-10P-F-VH-XHP2

To facilitate low voltage DC connections in parallel configuration the PSU-10-VH-XHP2 distribution box measures 55x30x22mm and features 10 output ports for multiple connections. Input is via a 2 pin JST VH socket with JST XHP-2 series connectors on the 10 output ports.

The unit is compatible with our interconnection system for our range of constant voltage LED strips, modules and assemblies

PSU-10P-F-VH-XHP2

In addition to our standard 10-way distribution box we offer the PSU-10-F-VH-XHP2 Fused distribution box for added circuit protection.

  • Dimensions:55x30x22mm
  • Single 2-pin JST VH input port
  • 10 individual  JST XHP 2-pin output ports
  • Rated at 2A/port

Compatible with our interconnection system for our range of constant voltage LED strips, modules and assemblies

PSU-10P-FR-VH-XHP2

In addition to our standard 10-way distribution box we offer the PSU-10-FR-VH-XHP2 Fused distribution box for added circuit protection.

  • Dimensions:55x30x22mm
  • Re-settable fused ports
  • Single 2-pin JST VH input port
  • 10 individual  JST XHP 2-pin output ports
  • Rated at 24VDC 2A/port

PSU-10S-VH-XHP2

To facilitate low voltage dc connections in series configuration the PSU-10S-VH distribution box measures 55x30x22mm and features 10 outputs for multiple connections. Input is via a 2 pin JST VH socket with JST XHP-2 series connectors on the 10 output ports.

 Compatible with our interconnection system for our range of constant current LED strips, modules and assemblies.

LA901P series

The LA901P series distribution boxes facilitate multiple connection to RGB strips & modules based on 4-way low voltage DC connections in parallel.

LA901P-4 measure 51.5x31x16.6mm with 4 output ports

LA901P-10 measure 77x31x16.6m with 10 output ports

Units are designed to be compatible with our interconnection system for our range of constant voltage LED strips, modules and assemblies

RGB & RGBW LED Strip Connectors

The D4-RGB and D5-RGBW LED strip connectors are supplied as a set of Male + Female with 100mm wire ends.

These connectors are designed to be compatible with our range of flexible and rigid LED strips.

Flexible LED Strip Connectors

Our range of flexible LED strip connectors facilitate easy connection and termination of linear strip schemes. Connectors are multi-pole press & connect IDC to reduce wire preparation

  • 2-way for mono-colour strips
  • 3-way for colour tuneable and SPI
  • 4-way for RGB
  • 5-way for RGBW
  • IP20 and IP65
  • Max current rating 5A
  • Choice of FPC widths
  • Right angle types

QFSC-2  Flexible LED Strip Connectors

The QFSC-2 series flexible LED strip connectors facilitate easy connection to  two terminal mono-colour flexible LED  strips and are available in a range of widths.

  • 5mm to 10mm width
  • Press and connect IDC. No need to wire strip.
  • Power inlet and strip to strip join types
  • Max current rating 5A
  • IP20

These connectors are designed to be compatible with our i range of flexible mono-colour LED strips.

QFSC-4  Flexible LED Strip Connectors

The QFSC-4 series flexible LED strip connectors facilitate easy connection to four terminal RGB flexible LED  strips.

  • 10mm width
  • Press and connect IDC. No need to wire strip.
  • Power inlet and strip to strip join types
  • Max current rating 5A
  • IP20

These connectors are designed to be compatible with our range of flexible RGB LED strips.

QFSC-5  Flexible LED Strip Connectors

The QFSC-5 series flexible LED strip connectors facilitate easy connection to five terminal RGBW flexible LED  strips.

  • 12mm width
  • Press and connect IDC. No need to wire strip.
  • Power inlet and strip to strip join types
  • Max current rating 5A
  • IP20

These connectors are designed to be compatible with our range of flexible RGBW LED strips.

QFSC-2R  Flexible LED Strip Connectors

The QFSC-2R series flexible LED strip connectors facilitate easy right angle connection to two terminal flexible LED  strips.

  • 10mm width
  • Press and connect IDC. No need to wire strip.
  • Power inlet and strip to strip join types
  • Max current rating 5A
  • IP20

These connectors are designed to be compatible with our range of flexible LED strips.
