Digital Addressable 1515 SOB
As an upgrade to COB LED strips the SOB technology provides an even & comfortable dot-free light. Dynamic lighting effects can be created as the LED sections can be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED controllers.
- Operating voltage 24VDC
- Power rating 15W/m
- 360 LEDs/metre
- 1174lm/metre
- CRI Ra>90
- Cuttable at 83.33mm (30 LEDs)
- Choice of IP ratings IP20, IP65, IP67, IP68
PF5000x10-188DL1515SOB-x-24V PDF
Digital Addressable COB RGB
Smooth, dot-less dynamic lighting effects can be created in multi-colour RGB using the PFA3000-COB-RGB. The strip allows each single RGB LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 5VDC
- Density 320LEDs/metre 24W/m
- 5050RGB 4-in-1 +IC LED emitter
- Integrated SK6812 SPI driver IC
- Cuttable at 15.72mm intervals
- Choice of IP ratings IP20, IP65, IP67
Digital Addressable 5050W
To enable dynamic lighting effects to be created using white light the PFA5050W allows each single white LED pixel to be addressed individually via Digital SPI signal. Using in conjunction with a range of SPI LED controllers.
- Operating voltage 12VDC
- Power rating 11W/m
- 5050 White 3-in-1 chip LED emitter
- UCS1903 onboard SPI driver IC
- Density 32 LEDs/metre 11W/m
- Cuttable at 31.25mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
PFA5050W Addressable Flexistrip PDF
Digital Addressable 5050RGB
To enable dynamic lighting effects to be created in a multi-colour the PFA5050RGB allows each single RGB LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 12VDC
- Power rating 11W/m
- 5050RGB 3-in-1 chip LED emitter
- UCS1903 onboard SPI driver IC
- Density 32 LEDs/metre 11W/m
- Cuttable at 31.25mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
PFA5050RGB Addressable Flexistrip PDF
Digital 5050RGB High Density
To enable dynamic lighting effects to be created in a multi-colour the PFA5050RGB-HD is allows each single RGB LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 12VDC
- Power rating 17W/m
- 5050RGB 3-in-1 chip LED emitter
- UCS1903 onboard SPI driver IC
- Density 50LEDs/metre 17W/m
- Cuttable at 20mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
Digital 5050RGB 60 LEDs/Metre
To enable dynamic lighting effects to be created in a multi-colour the PFA5050RGB-HD is allows each single RGB LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 12VDC
- Power rating 12W/m
- 5050RGB 3-in-1 chip LED emitter
- Choice of onboard (external) SPI driver IC
- Density 60LEDs/metre 12W/m
- Cuttable at 16.66mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
PFA5000x10-300DL5050RGB-12v PDF
Digital 5050RGB Integrated driver
To enable dynamic lighting effects to be created in multi-colour the PFA5050RGB 3-in1+IC allows each single RGB LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 12VDC
- Power rating 18W/m
- 5050RGB 3-in-1 +IC LED emitter
- Integrated 8208 (2815B) SPI driver IC
- Density 30LEDs/m 27W/m or 60 LEDs/m 54W/m
- Cuttable at 33.3mm or 16.66mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
PFA5050RGB+8208IC-Addressable PDF
Digital 5050RGBW Integrated driver
To enable dynamic lighting effects to be created in extended multi-colour the PFA5050RGBW 4-in1+IC allows each single RGBW LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 12VDC
- Power rating 17W/m
- 5050RGB 4-in-1 +IC LED emitter
- Integrated SK6812 SPI driver IC
- Density 50LEDs/metre 17W/m
- Cuttable at 20mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
PFA5050RGBW Addressable Flexistrip PDF
Digital LED Strip 5050RGB 5v
The 5050RGB-5V RGB LED strip is available in 30 or 60 LEDs per metre and enables dynamic lighting effects to be created in multi-colour. The 5050RGB 3-in1+IC allows each single RGB LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 5VDC
- Power rating 30 LED/m 7.2W/m
- Power rating 60 LED/m 14.4W/m
- 5050RGB 3-in-1 +IC LED emitter
- Integrated WS2812 6812 SPI driver IC
- Choice of density 30 or 60 LEDs/metre
- Cuttable at 16.6mm or 33.3mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
Digital LED Strip 3535RGB 5v
The high density 3535RGB-5V LED strip is configured with 144 LEDs/metre and enables bright dynamic lighting effects to be created in multi-colour. The 3535RGB 3-in1+IC LED emitters allow each single RGB LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 5VDC
- Power rating 144LED/m 7.2W/m
- Power rating 28.8W/m
- 3535RGB 3-in-1 +IC LED emitter
- Integrated WS2812 6812 SPI driver IC
- Choice of other densities
- Cuttable at 6.94mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
Digital 5050RGB 5v High Density
The ultra high density RGB LED strip comprises of 144 LEDs per metre and enables dynamic lighting effects to be created in multi-colour. The 5050RGB 3-in1+IC allows each single RGB LED pixel to be addressed individually via Digital SPI signal. Use in conjunction with a range of SPI LED Controllers
- Operating voltage 5VDC
- Power rating 36W/m
- 5050RGB 3-in-1 +IC LED emitter
- Integrated WS2812 SPI driver IC
- Density 144LEDs/metre
- Cuttable at 6.94mm intervals
- Choice of IP ratings IP20, IP65, IP67, IP68
Digital Flexible LED Strip Side Emit
To enable dynamic lighting effects to be created in multicolour the PFA5000 4020RGB Side emit series allows each single RGB LED pixel to be addressed individually via SPI signal. The series has a choice of LED density.
- Operating voltage 5V or 12VDC
- Power ratings 7.2W to 14.4W/m
- 4020RGB 3-in-1 chip + 5050W emitter
- Integrated SK6812 SPI driver IC
- Mid density 60 LEDs/metre 9.6W/m
- High density 100 LEDs/metre 19.2W/m
- Choice of IP ratings IP20, IP65, IP67, IP68
