Touch Panel LED Controllers

From our range of single and multi-zone wall mounted, touch panel LED controllers we offer a wide choice of communication protocols for the drive and control of LED products. The range is supported with LED receiver drivers and decoders in constant voltage and constant current outputs.  Also see our range of Rotary LED Controllers

  • Hard wired
  • Wireless RF 2.4Ghz
  • DMX 512
  • DALI
  • 0-10v control dimming
  • Multichannel for CT, RGB, RGBW, RGBWW control
  • Single and multi-zone control
  • Compatible with receiver drivers & decoders

Ltech Touch Panel Overview PDF

Touch Panel Overview PDF

Mi-Light Touch Panel Summary PDF

E Series

The E series LED Touch Dimmers and controllers are designed to drive LED strips and clusters. Panels are hard wired to constant voltage LED products and may be controlled directly from the touch panel or via F1 to F7 hand-held remote controls.

  • Low voltage 12-24VDC
  • 4A/channel
  • Hard Wired connection via terminal block
  • 1-Channel dimming
  • 2-Channel CT control
  • 3-Channel RGB control
  • 4-Channel RGBW control
  • 5-Channel RGBWY control
  • Control also via F1 to F7 hand held remotes

E1 - E4 Series PDF

E5S 5-Channel PDF

E1S-AD 0/1-10V PDF

EX Series Wireless RF & DMX

The EX series LED Touch Dimmers and controllers are designed to drive LED strips and clusters via RF wireless control or wired DMX. LED products may be controlled  via DMX decoder or via F series wireless receiver drivers. EX series also interface with Hand-held remote controls F and Q series and L-BUS smart gateway for WiFi control.

  • AC mains input 100-240VAC
  • DMX decoder or RF 2.4Ghz receiver/driver
  • Single or multi-zone
  • 1-Channel dimming
  • 2-Channel CT control
  • 3-Channel RGB control
  • 4-Channel RGBW control
  • Control via F series or Q series hand held remotes
  • 30 metre transmission distance

EX1 - EX4S Series PDF

EX5 - EX8S Series PDF

EDT1 to EDT3 DALI Touch Panels

The EDT1 to EDT3 are  touch panel LED dimmers designed to drive LED strips and clusters via DALI bus. Supports 1 to 3 Channel control using DALI standard protocol IEC62386 and is easy to set address.

  • Powered by DALI power supply
  • Dimming, Colour temp and RGBW control
  • Touch vibration
  • Control scene, group, unicast broadcast
  • Use in conjunction with DALI drivers
  • Supports DT8, Tc(EDT2) &  x-y(EDT3) color control

EDT1 - EDT3 PDF

DP1S to DP3S DALI Touch Panels

The DP1S to DP3S are  touch panel LED controllers designed to drive LED strips and clusters via DALI bus. Supports 1 to 3 Channel control using DALI DT6 / DT8 standard protocol to IEC62386 and is easy to set address.

  • Powered by DALI power supply
  • Dimming, CT, RGB and RGBW control
  • Easy address set using integrated display
  • DT8 needs only one DALI Address
  • Control scene, group, unicast broadcast
  • Use in conjunction with DALI drivers
  • 4 modes: scene, group, unicast & broadcast

DP1S - DP3S PDF

DALI DT6/DT8 RGBW Touch Panels

The SR-2300 RGBW series are  touch panel LED controllers designed to drive LED strips and clusters via DALI bus. Supports 4 Channel control using DALI DT6 / DT8 standard protocol to IEC62386 and is easy to set address.

  • Powered by DALI power supply
  • RGBW colour control
  • Easy address set by rotary switch
  • DT8 needs only one DALI Address
  • Single or 4 groups
  • Use in conjunction with DALI drivers
  • 8 built in colour scenes

SR-2300-RGBW-DT8 PDF

SR-2300-G4-RGBW-DT8 PDF

ECT-2 CT 0-10V x2 Touch Panels

The ECT2 touch panel LED dimmer control features 2 separate 0-10V output channels for LED colour temperature control and may be used in conjunction with the LM series  0-10v 2 channel LED drivers.

  • AC mains input 100-240VAC
  • 0-10v Dimming 2-channel colour temp
  • 4 scenes may be saved
  • Optional RF remote control
  • Communicates with F series & Q2 remotes
  • Compatible with L-BUS gateway (WIFI-108) for APP remote control

ECT2 PDF

LM series 0-10v CV drivers PDF

B1 & B1-B 4-Zone Dimming Touch Panels

The B1 (White) and B1-B (Black) RF touch panels are designed for dimming CV LED products  and may be used in conjunction with the FUT036W RF+WiFi LED drivers.

  • Battery powered 2x AAA. No wiring
  • RF 2.4Ghz
  • Single channel dimming control
  • Optional RF remote control
  • 4-Zone control
  • Use with FUT036W 2.4Ghz+WiFi  driver
  • Use with AC Triac dimming module TR1-C1

B1-B4_T1-T4 PDF

B0 RGB+CT Touch Panel

The B0 RF touch panel  is a 5-channel RGB+CT controller and may be used with FUT-045 FUT-039W receiver drivers and FUT-088 hand held remote control.

  • Battery powered 2x AAA. No wiring
  • RF 2.4Ghz
  • 5-Channel RGB + CT
  • Optional RF remote control FUT-088
  • Communicates with FUT-045 & FUT-039W
  • Compatible with WL-BOX1 gateway for App control via wifi

B0 PDF

B3 & T3 4-Zone RGBW Touch Panels

The B3 and T3 RF RGBW Touch panel LED controllers feature 4 channel RGBW LED control and dimming with 4-zone button select. Use in conjunction with  RF receiver LED drivers.

  • B3 Battery powered 2x AAA. No wiring
  • T3 AC mains powered
  • 4 channel RGB+W
  • 9 built-in colour scenes.
  • 30 metre transmission distance
  • Communicates with RF receiver/drivers
  • Compatible with FUT-09 hand-held remotes

B1-B4_T1-T4 PDF

B8 8-Zone RF RGBW Touch Panel

The B8 RF RGBW Touch panel LED controllers feature 4 channel RGBW LED control and dimming with 8-zone button select. Use in conjunction with RF receiver LED drivers.

  • B8 Battery powered AAA. No wiring
  • 4 channel RGB+W
  • RGB + CCT + 5-in-1 controller
  • 30 metre transmission distance
  • Compatible with FUT-89 hand-held remotes

B8 Datasheet PDF

EDA1 To EDA4 Key Touch Panels

The EDA1 to EDA4 are key touch panel LED dimmers designed to drive LED strips and clusters via DALI bus. The modules are easily mounted into a standard single gang wall plate.

  • DALI power supply
  • Supports 1 - 4 channels
  • Control scene, group, unicast broadcast
  • Use in conjunction with DALI drivers
  • Address set by DIP switch

EDA1 - EDA4 PDF

UX Series Touch Panels

The UX5 to UX8 series RF touch panel LED controllers offer a range of functions for driving LED strips and clusters. The panels are easily mounted into a standard single gang wall plate and combine DMX, RF, and WiFi control. Features include multiple changing modes and customised scenes.

  • UX5 Dimming control
  • UX6 CT control
  • UX7 RGB control
  • UX8 RGBW control
  • Pairs with R4 series receiver drivers
  • Pairs with WiFi-104
  • Built in colour changing modes
  • RJ45 DMX output

UX7 PDF UX8 PDF

MS-WF-512

The MS-WF-512 is an ultra thin wall mounted lighting control system.
The LCD colour screen offers simple and easy operation and integrates with the L-BUS system to provide DMX, WiFi and RF control.

  • Input Voltage 5V-24VDC
  • I-Phone, Android smart system applications
  • WiFi and DMX/RDM protocol
  • LAN control
  • Dimming, colour temp, RGB, RGBW, RGBWY
  • MS-10 hand-held remote control included

MS-WF-512 PDF

UB series Touch panel controllers

The UB series touch panels are ultra thin wall mounted LED lighting controllers. Compatible with BLE 5.0 Mesh and DMX512 protocols. The multi-touch capacitive LCD touch screen offers simple and easy operation.

  • Input Voltage 12-24VDC
  • Bluetooth 5.0 Mesh, DMX512
  • Dimensions: 120×75×30(mm)
  • 4-Zone control
  • 4-Programmable Scenes

View Bluetooth Mesh
